WEBPAGE UPDATED 08-08-2018



THE INTERTIE HAS JOINED THE SOUTHEASTERN LINKED REPEATER NET

ON WEDNESDAY AT 9 PM

(INFO @ SELINKEDREPEATER.NET)







FEATURED REPEATER OF THE MONTH CAN BE SEEN AT THE BOTTOM OF THIS PAGE



IRWINTON...WB4NFG...147.240+...77.0 TONE

AND

PEACH STATE INTERTIE HUB REPEATERS





FOR SALE



CUSTOM BUILT 100 WATT VHF REPEATER WITH UHF LINK PORT RADIO AND DUPLEXER

SEE AT BOTTOM OF THIS PAGE







THIS IS THE PEACH STATE EMERGENCY INTERTIE SYSTEM.........





"NEW HAM OPERATORS"................PLEASE READ THE MAYTAG'S BLOG SECTION

______________________________________________________________________________________



ARE YOU READY?

IS YOUR EMERGENCY PLAN IN PLACE?

HAVE YOU MADE PROVISIONS FOR EMERGENCY POWER?

____________________________________________________________







The PEACH STATE INTERTIE is a system that involves the linking of individual repeater systems into

one large unified system.



The primary purpose of the intertie is to enhance the Amateur Radio Emergency Service, Skywarn, and General Amateur Radio Communications in the Middle Georgia area.



By utilizing linking technology, Peach State Intertie provides excellent coverage of a good portion of Central Georgia area and good

usable coverage into surrounding regions.



The intertie utilizes UHF frequencies to link member repeaters together which provides greater coverage over the Central Georgia area.



The intertie gives users that are operating with handheld and mobile radios coverage abilities they have never had before.



The extended coverage the intertie provides will only enhance the ability of the ARES and Georgia Skywarn Linked Repeater System

to function as a public service to our area.



We encourage the use of this intertie system by all radio amateurs as long as you uphold the high standards of practice our fraternity

has adopted and upheld through the years.



This intertie belongs to all of us.............enjoy it!



For inquiries on your repeater becoming a member of the Peach State Intertie...



Contact us at .......



PEACHSTATEINTERTIE@PEACHSTATEINTERTIE.COM





__________________________________________________________________________________________________





Intertie Repeaters and Echo Link Nodes



(Full Time Linked Repeaters)





Irwinton 147.24+ (77.0 Tone) ONLINE



Irwinton 443.275+ (77.0 Tone) ONLINE



Macon 146.895- (88.5 Tone) ONLINE



Cedargrove 147.150+ (123.0 Tone) ONLINE



Eastman 145.210 (103.5 Tone) ONLINE



Montezuma 146.640- (97.4 Tone) ONLINE



Bolingbroke/Forsyth 146.835- (77.0 Tone) ONLINEN



Sandersville 145.270- (77.0 Tone)OFFLINE TO INTERTIE.... REPEATER IS WORKING





Automatic Linked or Linked On Command Repeaters

(Part Time Linked)





Warner Robins 146.850- (No Tone) ONLINE





Warner Robins (Houston Medical Center) 146.670- (82.5 Tone) ONLINE



Warner Robins (Houston Medical Center) 443.150+ (82.5 Tone) ONLINE





Macon (Macon/Bibb EMA) 147.015+ (88.5 Tone) ONLINE



Macon (Macon/Bibb EMA) 443.075+ (88.5 Tone) ONLINE





Thomaston 147.390+ (131.8 Tone) ONLINE





Peach County 145.290- (82.5 Tone) ONLINE







STANDBY MODE



Monroe County Link To Hub Repeater For

Georgia Skywarn Net From Peachtree City National Weather Service

Fayetteville 444.600+ (77.0 Tone) Primary

Tyrone 444.675+ (77.0 Tone) Back-up







Thomaston 147.390- (Tone 131.8) (Remote Base) Alternate Link To

Georgia Skywarn Net From Peachtree City National Weather Service







_________________________________________



IRWINTO

WB4NFG...14.2

IRWINTON



WB4NFG...147.240+...77.0 HZ...TONE



PEACH STATE INTERTIE HUB REPEATERS



WB4NFG-1 APRS









400 FT ROHN 80 TOWER AT 505 FT ASL









TOP TO BOTTOM



LEFT RACK



CELLWAVE RF METERING PANEL

ARCOM RC-210 REPEATER CONTROLLER

MOTOROLA MTR2000 REPEATER

18DB GAIN TX/RX PREAMPLIFIER ON REPEATER RECEIVER

TPL POWER AMPLIFIER SET TO 75 WATTS OUTPUT

ASTRON 50 AMP POWER SUPPLY

WB4NFG-1 APRS TRANSCEIVER ON LEFT

VHF REMOTE BASE TRANSCEIVER TO THOMASTON ON RIGHT

GLENAYRE POWER SUPPLY FOR HUB REPEATER 2



RIGHT RACK



CELLWAVE DUPLEXER FOR HUB REPEATER 1

GLENAYRE POWER AMPLIFIER FOR HUB REPEATER 1 SET TO 50 WATTS OUTPUT

HUB REPEATER 1 RECEIVER OF LEFT

18DB GAIN CELLWAVE PREAMP MOUNTED ON TOP OF RECEIVER

HUB REPEATER 1 EXCITER ON RIGHT

ASTRON 60 AMP POWER SUPPLY

HUB REPEATER 2 RECEIVER ON LEFT

HUB REPEATER 2 EXCITER ON RIGHT

DB PRODUCTS DUPLEXER FOR HUB REPEATER 2

GLENAYRE POWER AMPLIFIER FOR HUB REPEATER 2 SET TO 50 WATTS OUTPUT



DB-4060 DUPLEXER FOR VHF REPEATER BEHIND RACKS





FOR SALE



CUSTOM BUILT 100 WATT VHF REPEATER WITH UHF LINK PORT RADIO AND DUPLEXER



REPEATER CHASIS IS MOTOROLA MSR2000

MOTOROLA POWER SUPPLY TPN1191A

REPEATER CONTROLLER IS ARCOM RC-210

POWER AMPLIFIER IS MICOR 100 WATT CONTINOUS DUTY

UHF LINK RADIO IS MOTOROLA MAXTRAC WITH POWER CONTROL MOD

REPEATER RECEIVER IS MOTOROLA GM300

REPEATER EXCITER IS MOTOROLA GM300

EXTERNAL COOLING FAN RELAY INSTALLED

COOLING FANS ON REPEATER PA AND LINK RADIO

DOUBLE SHIELDED RG-142 CABLE ON ALL RF LINES



WILL PROGRAM CONTROLLER...RADIOS...AND TUNE DUPLEXER TO YOUR SPECS



AS BUILD SCHEMATIC OF ALL INTERCABELING AND WIRING INCLUDED





BUILD BY MAYTAG MARCH 2018



IF INTERESTED MAKE ME AN OFFER

ALL INTERCABELING INCLUDED......ALL YOU NEED IS AN ANTENNA



EMAIL ME AT WB4NFG@PEACHSTATEINTERTIE.COM

WITH NAME AND PHONE NUMBER



COMES WITH A LIMITED MAYTAG WARRANTY



WACOM WP-641 DUPLEXER



___

ANTENNA PORTS



_______________________
